2-34
10 - FUSES AND RELAYS UNDER THE ENGINE HOOD
- Open the engine hood, remove cover 1 in order to gain access to the fuses and relays, Replace a used fuse with a new fuse of the same
quality and capacity. Never reuse a repaired fuse.
1st ASSEMBLY (UP TO MACHINE N°: 586522)
K20 - Pre-heating relay.
K27 - OPTION Diesel decongealant relay.
MINIFUSE F1 TO F10
F1 - (20A MAX.) - OPTION Diesel decongealant (20A).
F2 - - OPTION.
F3 - - OPTION.
F4 - - OPTION.
F5 - (20A MAX.) - Star ter solenoid (20A).
F6 - (2A MAX.) - OPTION Diesel decongealant (2A).
F7 - - OPTION.
F8 - - OPTION.
F9 - - OPTION.
F10 - - OPTION.
MAXIFUSE F1 TO F6
F1 - (40A MAX.) - Power supply for fuses in the cab (40A).
F2 - (70A MAX.) - Keyed ignition switch (70A).
F3 - (20A MAX.) - OPTION.
MT 1436 R PRIVILEGE
- Electronic box MP2 (20A).
MT 1840 R PRIVILEGE
F4 - (40A MAX.) - Electronics box MP1 (40A).
F5 - (80A MAX.) - Preheating I.C. engine (80A).
F6 - (80A MAX.) - Alternator (80A).
2nd ASSEMBLY (FROM MACHINE N°: 586523)
K20 - Pre-heating relay.
K27 - OPTION Diesel decongealant relay.
MINIFUSE F51 TO F60
F51 - (20A MAXI) - OPTION Diesel defreezer (20A).
F52 - - OPTION.
F53 - - OPTION.
F54 - - OPTION.
F55 - (20A MAXI) - Starter solenoid (20A).
F56 - (2A MAXI) - OPTION Diesel defreezer (2A).
F57 - - OPTION.
F58 - - OPTION.
F59 - - OPTION.
F60 - - OPTION.
MAXIFUSE F41 TO F46
F41 - (20A MAXI) - OPTION.
MT 1436 R PRIVILEGE
- Electronic box MP2 (20A).
MT 1840 R PRIVILEGE
F42 - (70A MAXI) - Keyed ignition switch (50A).
F43 - (80A MAXI) - Alternator (80A).
F44 - (40A MAXI) - Electronics box MP1 (40A).
F45 - (40A MAXI) - Power supply for fuses in the cab (40A).
F46 - (80A MAXI) - Engine preheating (80A).
N° 265299
F6
K20
F5
F4
F3
F2
F1
F10
F9
F8
F7
F6
F5
F4
F3
F2
F1
80A
80A
40A
20A
70A
40A
CAB
MP2
MP1
20A
K27
1
N°293056
K20
F60
F59
F58
F57
F56
F55
F54
F53
20A
F52
F51
F41
F42
F43
F44
F45
F46
20A
50A
80A
40A
40A
80A
CAB
MP1
MP2
K27
1
