2-40
26 - LEVEL INDICATORS
A - TILT INDICATOR
When the two marks are aligned, the chassis is
parallel with the front axle.
B - SPIRIT LEVEL
Enables the operator to check that the lift truck is
in the horizontal position.
27 - DOOR OPEN LEVER
28 - DOOR CLOSE HANDLE
29 - WINDOW REGULATOR SWITCH
30 - SIDE STORAGE SPACE
31 - ROOF LIGHT
32 - HANDLE FOR REAR WINDOW OPENING
EMERGENCY EXIT
Use the rear window as an emergency exit, if it is impossible to leave the cab by the door.
33 - HANDLE FOR REAR WINDOW CLOSING
34 - DOCUMENT HOLDER NET
Make sure that the operator’s manual is in the right place, i.e. in the document holder net.
35 - STORAGE COMPARTMENT
36 - ASHTRAY
A
B
