25
R7 EXPERT / PRO SERVICE GUIDE
R7 Expert 27.5" exploded view
ITEM PART DESCRIPTION KIT NUMBER
1 KIT, CSA 32MM 80/120, 19.25MM OS, GBLK, BLK LEG (STANDARD OFFSET) 141-38117-K002
KIT, CSA 32MM 80/120, 12.25MM OS, GBLK, BLK LEG (SHORT OFFSET) 141-38117-K005
2 KIT, IVA, TALL 32MM M29.6X0.75 THREAD (REPLACES FIXED VOLUME SPACER SHOWN) 141-38117-K022
3 KIT, CASTING, 32MM 27.5" GBLK (INCL. BUSHINGS AND SEALS) 141-38117-K023
4A KIT, AXLE, HEXLOCK LIGHTWEIGHT (INCL. HARDWARE) 141-33147-K005
4B KIT, AXLE, QR15 BOOST (OPTION, REPLACES 5A, INCL. HARDWARE) 141-28131-K028
5A KIT, HARDWARE, HEXLOCK AXLE 141-33147-K003
5B KIT, HARDWARE, QR15 AXLE 141-28131-K024
6 KIT, BUSHING 32MM 141-38117-K017
7 KIT, SEAL 32MM 141-38117-K016
8 KIT, REBOUND DAMPER, 27.5"/29” 80/120 141-36683-K008
9 KIT, COMPRESSION DAMPER, VTT 141-38117-K014
10 KIT, EXPERT AIR, 32MM 27.5"/29” 80/120 141-38117-K011
11 KIT, 32MM KNOB, VTT & ADJ RBND 141-38117-K018
12A KIT, HOSE CLAMP, MY20 MEZZER & KIDS FORK 141-36103-K003
12B KIT, FENDER, MY20 MEZZER & KIDS FORK (INCL. 12A) 141-36103-K001
KIT, ASSY, MILO AL W/CABLE & HOUSING 193-24931-C017
KIT, ASSY, MILO REMOTE LOCKOUT, LEVER & CABLE 141-31975-K003
KIT, DECAL, MY21 R7 141-38117-K021
KIT, REBUILD 32MM 141-28528-K010
