31
R7 EXPERT / PRO SERVICE GUIDE
R7 PRO 27.5+/29" exploded view
ITEM PART DESCRIPTION KIT NUMBER
1 KIT, CSA 32MM 80/120, 19.25MM OS, SLVR, BLK LEG (STANDARD OFFSET) 141-38117-K003
KIT, CSA 32MM 80/120, 12.25MM OS, SLVR, BLK LEG (SHORT OFFSET) 141-38117-K006
2 KIT, IVA, 32MM 141-38117-K022
3 KIT, CASTING, 32MM 27.5+/29" GBLK (INCL. BUSHINGS AND SEALS) 141-38117-K024
4A KIT, AXLE, HEXLOCK LIGHTWEIGHT (INCL. HARDWARE) 141-33147-K005
4B KIT, AXLE, QR15 BOOST (OPTION, REPLACES 4A, INCL. HARDWARE) 141-28131-K028
5A KIT, HARDWARE, HEXLOCK AXLE 141-33147-K003
5B KIT, HARDWARE, QR15 AXLE 141-28131-K024
6 KIT, BUSHING 32MM 141-38117-K017
7 KIT, SEAL 32MM 141-38117-K016
8 KIT, REBOUND DAMPER, HALF-CART 32MM 27.5/29” 80/120 141-38117-K013
9 KIT, COMPRESSION DAMPER, VTT PRO 32MM 141-38117-K015
10 KIT, DORADO AIR, 32MM 27.5/29” 80/120 141-38117-K012
11 KIT, 32MM KNOB, VTT PRO & ADJ RBND 141-38117-K019
12A KIT, HOSE CLAMP, MY20 MEZZER & KIDS FORK 141-36103-K003
12B KIT, FENDER, MY20 MEZZER & KIDS FORK (INCL. 12A) 141-36103-K001
KIT, ASSY, MILO AL W/CABLE & HOUSING 193-24931-C017
KIT, ASSY, MILO REMOTE LOCKOUT, LEVER & CABLE 141-31975-K003
KIT, DECAL, MY21 R7 141-38117-K021
KIT, REBUILD 32MM 141-28528-K010
KIT, MATTOC SERVICE TOOL (8MM THIN-WALL SOCKET, 24MM FLAT SOCKET, & END
CAP SOCKET)
172-31133
