INTRODUCTION 999 LUFFING JIB OPERATOR MANUAL
1-4
Published 05-15-17, Control # 043-09
2 ft, 2 in (0,7 m) link (each) with pin - - -
115 52
8-1/2 in (216 mm) link (each) with pin - -
45 20
9 ft, 1-1/4 in (2,8 m) strap (each) - - - -
120 54
BOOM NO. 82:
30 ft (9,1 m) butt - - - - - -
6,615 3 000
40 ft (12,2 m) top (with 8 sheave lower point and 3 sheave wire rope guide)
11,230 5 093
10 ft (3,0 m) insert with wire rope guide
2,270 1 029
10 ft (3,0 m) insert - - - - - -
1,820 825
20 ft (6,1 m) insert (with jib backstay lugs)
2,530 1 147
40 ft (12,2 m) insert - - - - - -
4,400 1 995
40 ft (12,2 m) insert (with jib backstay lugs)
4,430 2 009
37 ft, 7-1/4 in (11,5 m) basic strap with link (each)
445 201
10 ft (3,0 m) strap with link (each) - - -
160 72
20 ft (6,1 m) strap with link (each) - - -
275 124
40 ft (12,2 m) strap with link (each) - - -
480 217
Upper boom point (single sheave) - - -
920 417
Wire rope guide (top) - - - - -
1,845 836
Wire rope anchor - - - - -
285 129
Wire rope roller assembly (auxiliary drum)
335 151
Wire rope guide (butt) - - - - -
2,490 1 129
Boom stop assembly (each side) - - - -
765 346
JIB NO. 134:
15 ft (4,6 m) butt - - - - - -
580 263
15 ft (4,6 m) top (with jib point) - - - -
990 449
10 ft (3,0 m) insert - - - - - -
350 158
20 ft (6,1 m) insert - - - - - -
580 263
30 ft, 9 in (9,4 m) basic pendant (each) -
115 52
9 ft, 6 in (2,9 m) pendant (each) - - - -
65 29
19 ft (5,8 m) pendant (each) - - - - - -
85 38
12 ft, 6 in (3,8 m) strut with sheave - -
665 301
Backstay link (each) attached to strut -
25 11
Backstay tie link - - - - - -
10 4
Backstay link (each) - - - - - -
65 29
Backstay spreader - - - - - -
50 22
44 ft, 7 in (13,6 m) backstay pendant (each)
150 68
4 ft, 8 in (1,4 m) backstay pendant (each)
50 22
Backstay link (each) attached to boom insert
20 9
Jib stop assembly - - - - - -
175 79
Wire rope anchor - - - - - -
70 31
Winch - - - - - -
35 15
Load sensor - - - - - -
110 49
Jib adaptor (required for No. 82LR boom)
400 181
LUFFING JIB NO. 149:
25 ft (7,6 m) butt - - - - - -
3,275 1 485
25 ft (7,6 m) top (with main and upper jib point, wire rope guide, hand winch, and strap links)
5,875 2 664
10 ft (3,0 m) insert - - - - - -
1,060 480
20 ft (6,1 m) insert - - - - - -
1,710 775
20 ft (6,1 m) intermediate fall insert - -
2,665 1 208
40 ft (12,2 m) insert - - - - - -
2,995 1 358
Weight
Pounds Kilograms
