Manitowoc Published 05-15-17, Control # 043-09 1-3
999 LUFFING JIB OPERATOR MANUAL INTRODUCTION
1
CRANE AND LUFFING JIB WEIGHTS
NOTE: Weights may fluctuate ±3% due to manufacturing
tolerances.
Weight
Pounds Kilograms
LIFTCRANE - BOOM NO. 82:
Upperworks and lowerworks complete, 48 in (1 219 mm) crawler treads, counterweight, gantry,
backhitch, mast, fully rigged 70 ft (21,3 m) Boom No. 82 [including single sheave upper boom
point, 8 sheave lower point, 3 sheave wire rope guide, lower wire rope guide, 250 Ton (227t)
block, and 15 Ton (14t) hook and weight ball], boom stops and maximum length hoist and whip
lines
999 Series 1
349,420 158 494
999 Series 2
428,445 194 339
999 Series 3
499,465 226 553
UPPERWORKS MACHINERY MODULE WITH CARBODY:
Carbody, upperworks with two full power drums, operator’s cab, gantry, backhitch, mast, boom
hoist wire rope, carbody jacking arrangement (optional), and maximum length hoist and whip
lines - - - - - -
87,500 39 689
CRAWLERS:
28 ft, 2 in (8 585 mm) crawler assembly with platforms, steps
and 48 in (1 219 mm) treads (each) - -
43,260 19 622
COUNTERWEIGHT - UPPER:
Box - Side (6 on 999 Series 1; 8 on Series 2; 10 on Series 3) with pins (each)
17,500 7 937
Box - Center - - - - - -
23,500 10 659
Tray - Lower counterweight - - - - - -
21,050 9 548
Total upperworks counterweight 999 Series 1
149,600 67 857
999 Series 2
184,600 83 733
999 Series 3
219,600 99 608
COUNTERWEIGHT - UPPER — LOW-PROFILE:
Box - Side (12 required) with pins (each)
14,485 6 570
Box - Center - - - - - -
23,500 10 659
Tray - Lower counterweight - - - - - -
21,050 9 548
Total upperworks counterweight - 999 Series 3 only
219,600 99 608
COUNTERWEIGHT - LOWER:
Carbody Counterweight (2 on Series 2, 4 on Series 3) (each)
Upper Box
18,000 8 164
Lower Box
22,000 9 979
GANTRY:
10 ft, 2-3/4 in (3 118 mm) Gantry (with nylon sheaves)
4,430 2 009
Backhitch cylinders and pins (each) - -
1,030 467
Counterweight handling links and pins (each)
155 70
MAST FOR BOOM NO. 82:
30 ft (9 144 mm) mast (with nylon sheaves)
5,100 2 313
Pendant link on mast (each) - - - - - -
155 70
