12
Water Connections for the AR-10000,
AR-20000 and AR-40000 Filter Systems
• Turn off water supply.
• Attach inlet and outlet water
lines.
– To install water lines into
John Guest fittings:
! Be sure tubing is high
quality, exact size and
roundness and has no
nicks or scratches.
! Tubing end must be clean
and square. Use tubing
cutter or sharp razor knife
if necessary.
! Push tubing into the fitting
as far as it will go then pull
back to seat o-ring.
• Stainless threaded fittings are provided as
optional connections.
Water Connections for the AR-10000,
AR-20000 and AR-40000 Filter Systems
Correct End Cut
Incorrect End Cut
