OPERATING CONTROLS AND PROCEDURES GRT8100 OPERATOR MANUAL
3-28 Published 3-25-2020, Control # 595-10
override the RCL, turn switch OFF for 1 second
then ON again. The RCL will be bypassed.
Set Boom
Turn jog dial clockwise to set boom, including aux nose and
reeving options.
NOTE: If no jib configuration is chosen for the boom, the
following selection will be for reeving.
Set Jib Length (if installed)
Turn jog dial clockwise and select to determine and choose
the length of the jib, including inserts.
Set Jib Angle (if installed)
Turn jog dial clockwise to program the jib angle after length is
selected.
Hoist Selection
Turn jog dial clockwise to select between main and auxiliary
hoists.
