11Grove RT9130E
THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane
Load chart
NOTES:
1. All capacities above the bold line are based on
structural strength of boom extension and do
not exceed 85% of tipping loads, in accordance
with SAE J-765.
2. 36 ft boom extension may be used for single or
double line lifting service. 59 ft boom extension
may be used for single line lifting service only.
WARNING: Lifting with the 36 ft extension
base, with the 23 ft extension fly either erected
or folded along side of extension base, is strictly
prohibited.
3. Radii listed are for a fully extended boom with
the boom extension erected. For main boom
lengths less than fully extended, the rated
loads are determined by boom angle. Use only
the column which corresponds to the boom
extension length and offset for which the
machine is configured. For boom angles not
shown, use the rating of the next lower boom
angle.
WARNING: Operation of this machine with
heavier loads than the capacities listed is
strictly prohibited. Machine tipping with boom
extension occurs rapidly and without advance
warning.
4. Boom angle is the angle above or below
horizontal of the longitudinal axis of the boom
base section after lifting rated load.
5. Capacities listed are with outriggers properly
extended and vertical jacks set only.
Pounds
130 ft
40,000 lb36 ft - 59 ft
100%
27 ft 10 in
spread
360°
Feet
0°
OFFSET
20°
OFFSET
40°
OFFSET
0°
OFFSET
20°
OFFSET
40°
OFFSET
#0021 #0022 #0023 #0041 #0042 #0043
36 ft LENGTH
59 ft LENGTH
