Installation and Service Manual
OPERATION
MII-402 MEASUREMENTS & SPECIFICATIONS
Standard Features for the MII-402:
Timed agitation, lighted merchandiser (MM), graphics,
key switches (DS) and drain kits (DRK). Leg kits not avail-
able for this unit.
Dimensions:
60" (152.4 cm) W x 30.5" (77.5 cm) D x 32.25 (81.9 cm) H
Ice Storage Capacity:
400 lbs. (181.82 kg)
Cooling Capacity:
At 75
o
F ( 23.9
o
C) ambient temperature. Up to 8 (12 oz.)
drinks per minute can be dispensed at or below 40
o
F
(4.4
o
C) provided ice is in full contact with the cold plate.
Cabinet and Ice Bin:
Stainless steel
Cold Plate:
16 valve: 19.85"W x 28.23"H; Two 12 circuit cold plates
each with 3-1-1-3 manifold.
20 valve: 19.85"W x 28.23"H; Two 15 circuit cold plates
each with 3-1-2-1-3.
Electric:
Models available in 120/60/1; 8 foot, three-wire cord and
plug provided.
Amperage:
4.5 FLA standard merchandiser; 5.0 FLA 34" extended
merchandiser.
Drain:
Four 3/4" PVC drain fittings, (two pre-installed 3/4" PVC
(N.P.T.) drain fittings extend from drain pans and two pre-
installed 3/4" PVC (N.P.T.) drain fittings extend from each
bin.) Unit can be drained from the bottom or the back of
the unit.
Graphic Area Dimensions:
Physical trim area on merchandisers:
1 2 T: 60"W x 12"H x 6 3/8"D
2 4 T: 60"W x 24"H x 7 1/4"D
3 4 T: 60"W x 34"H x 7 1/4"D
Ice Cube Compatibility:
Dispenses cube ice up to one inch square. Flake ice is
not compatible. Compatible with most 30" or 48" wide
ice machines. Contact factory for details.
Ice Machine Compatibility:
Front or side manual fill or top mount with any single 30"
or 48" wide ice machine. Certain top mounted cubers
may reduce storage capacity. Contact distributor or fac-
tory for baffle and special lid requirements for top-
mounted cuber applications.
Service:
Drain pan, beverage valves, (optional) cold plate hook
ups, drain connections and electrical components are
all front serviceable.
Ship Weight:
600 lbs (272 kg)
Counter Top Weight (without ice):
500 lbs (227 kg)
Options:
16 or 20 Flomatic valves (fast flow, push button, sanitary
lever, or portion control).
Other options include: Water dispenser, carbonator,
regulator and installation kits.
