Part Number 020002365 08/25/2015 9
General
Refrigeration units require stand or 6" (15.2 cm) legs.
Refrigeration unit cannot be placed directly on floor.
Conduit can be run through floor or ceiling chase.
Syrup supply can be located on stand or adjacent to
refrigeration unit.
Dimensions and Clearances — All Models
Wall
6" (15.2 cm)
Diameter Chase minimum
3-7/8" (9.8 cm) Diameter
(4-7/8" [12.4 cm] Diameter
on Model 50)
Air Flow
Control
Switches
18"
(45.7 cm)
minimum
J
Electrical
Junction Box
6" (15.2 cm) minimum
12"
(30.5 cm)
minimum
Wall
Wall
Top View
Front ViewSide View
P
Wall
Electrical
Junction Box
Incoming Water
Line
Incoming CO
2
Supply Line
Incoming Syrup
Supply Lines
Drain Connection
W
Ceiling
Wall
18" (45.7 cm)
minimum
I
H
CO
2
Regulator
Panel (Optional)
N
Drain Connection
Floor drain should be located
within 6 ft (183 cm) of unit
Wall
Conduit to
Dispensing Towers
D
Water Condenser Connections
(Models 42, 44 and 50 only)
K
Incoming Water
Connection
Drain Connection
L
M
Model W D H
I
(with stand)
J K L M N P
42, 44 &
SC1000
39-3/4"
(101 cm)
24-3/4"
(62.9 cm)
28-1/4"
(72.4 cm)
60-3/4"
(154.3 cm)
11"
(28 cm)
3-1/2"
(8.9 cm)
12"
(30.5 cm)
4"
(10.2 cm)
6"
(15.2 cm)
12"
(30.5 cm)
50 &
SC2000
42-1/4"
(107.3 cm)
28-1/4"
(71.8 cm)
32-1/4"
(81.9 cm)
66-3/4"
(169.5 cm)
11"
(28 cm)
4"
(10.2 cm)
19"
(48.2 cm)
19"
(48.2 cm)
8-1/2"
(21.6 cm)
14"
(35.6 cm)
Section 2
Installation
