OUTRIGGERS NBT40 SERVICE MANUAL
7-2 Published 8-01-2017 Control # 287-11
Lock Pin
FIGURE 7-1
1
ST
Section Beam
2
ND
Section Beam
Extend Cylinder
Anchor Bolts
Top Cable
Adjustment
Outrigger
Box
Outrigger Float
Bottom Cable
Adjustment
Stabilizer
Hydraulic LInes
Reference Only
