3
National Crane Published 8-01-2017 Control # 287-11 3-3
NBT40 SERVICE MANUAL ELECTRIC SYSTEM
CAB MODULE, FUSE, RELAY PANEL
The cab and superstructure fuse/relay panel (9, Figure 3-2)
is located behind the operators seat. Remove the two
screws securing the access panel to gain access to the fuse
blocks, relays, cab control module, interface connectors and
the cab RCL module.
NOTE: The cab control modules and RCL module are not
serviceable; contact Crane Care Customer Service
with any service or repair questions about the
modules.
FIGURE 3-1
1
3
2
4
5
6
7569-10
7569-11
7569-2
7
Reference Only
