LUBRICATION NBT40 SERVICE MANUAL
8-16 Published 8-01-2017 Control # 287-11
Item Description
1 Hoist Plumbing Connections
2 Tension Spring
3 Counterweight Pins
4
All Hardware, Clips, Pins, Hose Connections
not painted O/R Pins, Clips
5 Valvebank, Hose Connections inside turntable
6 Boom Extension Hardware (Optional)
7 Pivot Shaft
8 Boom Nose Pins, Clips
9 Headache Ball/Hook block
10 O/R Pins, Clips
11 Mirror Mounting Hardware
12 Powertrain Hardware
13 O/R Hose Connections
14 Entire underside of unit
15 Turntable Bearing Fasteners
16 Wire Rope
17 Outrigger Beam Hardware
