National Crane Published 8-01-2017 Control # 287-11 9-3
NBT40 SERVICE MANUAL CRANE INSTALLATION
Typical Serial Number Location
1
2
3
4
5
FIGURE 9-1
7
6
8
1Sub Base 5Turret
2 1st Section Boom 6 4th Section Boom
3 2nd Section Boom 7 5th Section Boom
4 3rd Section Boom 8 Lift Cylinder
