Manitowoc National Crane NBT40 Series Service Manual

National Crane Published 8-01-2017 Control # 287-11 1-11
NBT40 SERVICE MANUAL INTRODUCTION
1
10
M6x1.0
8.8 8.3 8.1 7.9
10.9 12.2 11.9 11.6
12.9 14.3 13.9 13.6
M8x1.25
8.8 20.2 19.7 19.2
10.9 29.6 28.9 28.2
12.9 34.7 33.8 33.0
M10x1.5
8.8 40.0 39.0 38.0
10.9 58.7 57.2 55.8
12.9 68.7 67.0 65.3
M12x1.75
8.8 69.7 68.0 66.2
10.9 102.4 99.8 97.2
12.9 119.8 116.8 113.8
M14x2
8.8 111.4 108.6 105.8
10.9 163.6 159.5 155.4
12.9 191.5 186.7 181.9
M16x2
8.8 172.8 168.5 164.1
10.9 253.8 247.4 241.1
12.9 296.9 289.5 282.1
M18x2.5
8.8 246.2 240.1 233.9
10.9 350.7 341.9 333.2
12.9 410.4 400.1 389.9
M20x2.5
8.8 348.0 339.3 330.6
10.9 495.6 483.2 470.8
12.9 580.0 565.5 551.0
M22x2.5
8.8 474.4 462.6 450.7
10.9 675.7 658.8 641.9
12.9 790.7 770.9 751.2
M24x3
8.8 601.3 586.3 571.3
10.9 856.4 835.0 813.6
12.9 1002.2 977.1 952.1
M27x3
8.8 881.6 859.6 837.5
10.9 1255.7 1224.3 1192.9
12.9 1469.4 1432.7 1395.9
M30x3.5
8.8 1195.3 1165.5 1135.6
10.9 1702.5 1659.9 1617.3
12.9 1992.3 1942.4 1892.6
Nominal Size, Threads per
Inch, and Series
Designation
Property
Class
Torque (Nm)
Maximum Nominal Minimum
Reference Only
