Part Number 80-01111-9 7/10 55
• Grasp ice damper and apply pressure toward
the left hand mounting bracket.
• Apply pressure to the right hand mounting
brac
ket with thumb.
• Pull ice damper forward when the right hand
ice da
mper pin disengages.
Installation
• Place ice damper pin in left hand mounting
b
racket and apply pressure toward the left
hand mounting bracket.
• Apply pressure to the right hand mounting
brac
ket with thumb.
• Push ice damper toward evaporator until right
h
and damper pin engages.
To Next Page
