Part Number 80-01111-9 7/10 227
Electronic Control Boards
QM20/QM30
-2
0
1
2
3
4
-
1
-
3
-5
-4
LIQUID LINE
THERMISTOR
CONNECTION
ICE BRIDGE
THICKNESS
CONTROL
POWER
LIGHT
8 AMP FUSE
