Manitowoc QM45 Series Technician's Handbook

72 Part Number 80-01111-9 7/10
SUMP DRAIN OVERFLOW TUBE
1. Remove clamp.
2. Pull down to remove overflow tube and tubing as
an assembly. The sump trough water will drain
into the bin.
3. Remove overflow tube from vinyl tubing by
pulling.
REMOVE CLAMP
AND
PULL DOWN
