Part Number 000015433_03 5/20 145
RFF1300/RFF2500
Compressor Wiring Legend
50 Compressor
51 Run Capacitor
52 Start Capacitor
53 Relay
54 Overload
(YEL)
(C)
(S)(R)
(YEL)
L1
L2
BLU
5
2
1
50
53
51
54
52
