Manitowoc RFF - RFF2500 Air-Cooled

Part Number 000015433_03 5/20 159
RFF2500 AIR-COOLED
1
2
3
4
5
6
7
8
8
Tubing Diagram Legend
1 Compressor
2 Condenser
3 Liquid Line Drier
4 Liquid Line Solenoid Valve
5 Suction Accumulator
6 Thermostatic Expansion Valve
7 Liquid Accumulator
8 Evaporator
