Manitowoc RFF Technician's Handbook

98 Part Number 000015433_03 5/20
RFF2200C WITH RCUF2200
QUIETQUBE REMOTE CONDENSER AIR COOLED
Characteristics vary depending on operating conditions
ICE PRODUCTION
Air Temperature
Water Temperature
24 Hour
Ice Production
-20°F/50°F
-29°C/10°C
2403 lbs
1090 kgs
70°F/50°F
21°C/10°C
2063 lbs
936 kgs
90°F/70°F
32°C/21°C
1702 lbs
772 kgs
120°F/70°F
49°C/21°C
1073 lbs
487 kgs
OPERATING PRESSURES PSIG& kPa
Air Temperature Around
Ice Machine
°F/°C
Freeze Cycle
Discharge
Pressure
Suction
Pressure
50°F PSIG
16°C kPa
175-200
1207-1379
26-31
176-214
70°F PSIG
21°C kPa
220-250
1517-1724
31-36
214-248
80°F PSIG
27°C kPa
225-275
1551-1896
32-37
221-255
90°F PSIG
32°C kPa
250-310
1724-2137
33-38
228-262
120°F PSIG
49°C kPa
365-410
2517-2827
38-43
262-296
