Manitowoc RFF - Page 43

Part Number 000015433_03 5/20 43
YES
Bin Thermostat
Closed?
NO
Replace Thermostat
Ice Contacting
Thermostat?
Remove Ice - Allow
To Warm And Retest
Adjusting Closes
Thermostat?
Verify New Setting Cycles
Machine On/O
Yes
No
No
Yes
Evaporator Safety
Thermostat Closed?
NO
Evaporator Cold?
Replace Thermostat
Allow Evaporator To
Warm And Retest
Adjusting Closes
Thermostat?
Verify New Setting Cycles
Machine On/O
Yes
No
No
Yes
YES
YES
RF0266 LPCO
