Manitowoc RN1078C

110 Part Number 000007661 6/13
Bin Thermostat
Closed?
NO
Replace Thermostat
YES
Ice Contacting
Thermostat?
Remove Ice - Allow
To Warm And Retest
Adjusting Closes
Thermostat?
Verify New Setting Cycles
Machine On/Off
YES
NO NO
YES
YES
Left Side Chute
Switch Closed?
NO
Adjust Or Replace
Actuator
Ice Contacting
Actuator?
Remove Ice And
Retest
Actuator Functions?
Replace Switch
YES
NO NO
YES
YES
Right Side Chute
Switch Closed?
NO
Adjust Or Replace
Actuator
Ice Contacting
Actuator?
Remove Ice And
Retest
Actuator Functions?
Replace Switch
YES
NO NO
YES
YES
