ICE CHUTE REMOVAL - RF MODELS
RF0300/RF0650/RF1200/RF2300
NOTE: A limited number of these models have the ice
chute listed on the previous page.
1. Place the toggle switch in the OFF position, turn
off the water supply and disconnect electrical
power to the ice machine.
2. Disconnect water supply.
3. Remove water reservoir cover.
4. Remove bin thermostat from ice chute.
5. Loosen bolts holding cross member.
6. Lift cross member and remove ice chute.
