Section 2 Installation Instructions
Part Number 000002477 3/08 2-29
Typical QuietQube® System Installation - S1470C/S1870C/S2170C
SV1768c
CVD CONDENSING
UNIT
ELECTRICAL
DISCONNECT
LIQUID
LINE
SUCTION
LINE
ELECTRICAL
DISCONNECT
ICE MACHINE
HEAD SECTION
SUCTION
REFRIGERANT
SHUT-OFF VALVE
LIQUID
REFRIGERANT
SHUT-OFF VALVE
ELECTRICAL
SUPPLY
BIN
POTABLE WATER
INLET
