Section 1 General Information
Part Number 000002477 3/08 1-1
Section 1
General Information
Model Numbers
This manual covers the following models:
For 3 phase electrical option: add the number “3” to the
end of model number (CVD10853).
How to Read a Model Number
Remote Condensing Unit
Ice Cube Sizes
Ice Machine Head Section CVD® Condensing Unit
SD0672C
SY0674C
IB0624YC
IB0622DC
CVD0675
SD0872C
SY0874C
IB0824YC
IB0822DC
CVD0885
SD1072C
SY1074C
CVD1085
IB1024YC
IB1022DC
CVD1185
SD1272C
SY1274C
CVD1285
SD1472C
SY1474C
CVD1485
CVD1486
SD1872C
SY1874C
CVD1885
SD2172C
SY2174C
CVD2085
PERSONNEL INJURY POTENTIAL
Do not operate equipment that has been misused,
abused, neglected, damaged, or altered/modified from
that of original manufactured specifications.
When installed on a bin an ice deflector is required.
Prior to using a non-Manitowoc ice storage system with
Manitowoc ice machines, contact the manufacturer to
assure their ice deflector is compatible with Manitowoc ice
machines.
S1470C/S1870C/S2170C ice machines are not
approved for use on Manitowoc B570 series bins.
Dice
7/8" x 7/8" x 7/8"
2.22 x 2.22 x 2.22 cm
Half Dice
3/8" x 1-1/8" x 7/8"
0.95 x 2.86 x 2.22 cm
S Y 1074 C
ICE MACHINE
MODEL
ICE CUBE SIZE
D DICE
Y HALF DICE
# CUBE SIZE
2 DICE
3 DICE
4 HALF-DICE
5 HALF-DICE
CONDENSER TYPE
AIR-COOLED
WATER-COOLED
AIR-COOLED
WATER-COOLED
A SELF-CONTAINED AIR-COOLED
W SELF-CONTAINED WATER-COOLE
C CVD REMOTE AIR-COOLED
7 CVD REMOTE
AIR-COOLED
CONDENSER TYPE
ICE MACHINE
SERIES
CVD 1485 3
CONDENSING
UNIT MODEL
3 PHASE
CONDENSING
UNIT SERIES
5 AIR-COOLED
6 WATER-COOLE
