192 Part Number 000014797 Rev02 05/18
BIN THERMOSTAT
Function
The bin thermostat stops the ice machine when the bin is
full. The level of ice in the ice storage bin controls the ice
machine shut-off. When the bin is full, ice cubes contact
the bin thermostat bulb holder, which cools down and
opens the bin thermostat to stop the ice machine. The ice
machine remains off until enough ice has been removed
from the bin. This causes the thermostat bulb holder to
warm and closes the bin thermostat, restarting the ice
machine.
Specifications
Control Setting
Bin Thermostat
Cut in: 40°F (4.5°C)
Cut out: 34°F (1.0°C)
n
Warning
Disconnect electrical power to the entire ice machine
before proceeding.
1. Remove the back panel to access the bin thermostat.
2. Disconnect both wires from the bin thermostat
and check the resistance across the bin thermostat
terminals
No Ice On Bulb Ice On Bulb Result
Closed Open Thermostat good
Open Closed Replace Thermostat
NOTE: After covering/uncovering the bulb holder with
ice, wait at least three minutes to allow the thermostat to
react. (Open/Close)
