Part Number 000014797 Rev02 05/18 231
Number Component
4 Bin Thermostat
5 Compressor
7 Compressor Overload
13 Compressor Start Relay
14 Condenser Fan Motor
17 Contactor Coil
18 Contactor Contacts
19 Control Board
23 Jumper Air cooled or
Drain Pump Safety Switch Water-cooled
28 Fuse
32 Ice Thickness Control
34 Light Harvest
40 On/Off/Clean Switch
41 See Control Board Schematic For Detail
42 Solenoid Valve Harvest
49 Thermistor Liquid Line
56 Water Inlet Valve
58 Water Pump
Refer to control board schematic for control board detail
