Manitowoc UDF0310A Technician's Handbook

122 Part Number 000014797 Rev02 05/18
DISCHARGE LINE TEMPERATURE ANALYSIS
GENERAL
Knowing if the discharge line temperature is increasing,
decreasing or remaining constant can be an important
diagnostic tool. Maximum compressor discharge line
temperature on a normally operating ice machine steadily
increases throughout the freeze cycle. Comparing the
temperatures over several cycles will result in a consistent
maximum discharge line temperature.
Ambient air temperatures affect the maximum discharge
line temperature.
Higher ambient air temperatures at the condenser = higher
discharge line temperatures at the compressor.
Lower ambient air temperatures at the condenser = lower
discharge line temperatures at the compressor.
Regardless of ambient temperature, the freeze cycle
discharge line temperature will be higher than 150°F (66°C)
on a normally operating ice machine.
PROCEDURE
Connect a temperature probe on the compressor discharge
line within 6” (15.2 cm) of the compressor. Observe the
discharge line temperature for the last three minutes of
the freeze cycle and record the maximum discharge line
temperature.

Manitowoc UDF0310A Specifications

General

Model	UDF0310A
Type	Undercounter Ice Maker
Voltage	115 V
Condenser Type	Air-Cooled
Water Connection	3/8" FPT
Refrigerant	R404A
Frequency	60 Hz
Width	30 inches
Ice Production Capacity	310 lb/day
Ice Storage Capacity	90 lb
