2-2 Part Number: 040003628 Rev. 01 01/14/18
Installation Instructions Section 2
Location of Ice Machine
The location selected for the ice machine must meet
the following criteria. If any of these criteria are not met,
select another location.
• The location must be indoors.
• The location must be free of airborne and other
contaminants.
• The air temperature must be at least 10°C (50°F),
but must not exceed 43°C (110°F).
• The location must not be near heat-generating
equipment or in direct sunlight.
• The location must be capable of supporting the
weight of the ice machine and a full bin of ice.
• The location must allow enough clearance for water,
drain and electrical connections in the rear of the ice
machine.
• The location must not obstruct airflow through or
around the ice machine (condenser airflow is in and
out the front). Refer to the chart below for clearance
recommendations:
Self-Contained
Air-Cooled
Self-Contained
Water-Cooled
Top/Sides 203 mm (8")* 127 mm (5")*
Back 127 mm (5") 127 mm (5")
NOTE: The ice machine may be built into a cabinet.
*There is no minimum clearance requirement for the
top or left and right sides of the ice machine. The listed
values are recommended for efficient operation and
servicing only.
Caution
The ice machine must be protected if it will be
subjected to temperatures below 0°C (32°F). Failure
caused by exposure to freezing temperatures is not
covered by the warranty.
Leveling the Ice Machine
Levelers are included with all ice machine. Legs are an
available option.
1. Screw the legs or levelers into the bottom of the ice
machine.
2. Screw the foot of each leg or leveler in as far
as possible. Move the ice machine into its final
position.
3. Level the ice machine correctly. Use a level on top
of the ice machine. Turn each foot as necessary to
level the ice machine from front to back and side to
side.
