Table 4. Basic construction of the ll station:
No. Part Catalogue-No.
1. Housing FPD-3001
2. Sticker FPD-3002
3. Grip attachment FPD-3003
4. Grip FPD-3004
5. Washer FPD-3005
6. Holder screw FPD-3006
7. Inlet socket FPD-3007
8. Washer FPD-3008
9. Inlet socket nut FPD-3009
10. Gauge FPD-3010
11. Pressure gauge connection FPD-3011
12. Gauge holder FPD-3012
13. Straight short tube FPD-3013
14. Three pin switch FPD-3014
15. O-ring FPD-3015
16. Straight connector FPD-3016
17. Straight long tube FPD-3017
18. Three pin switch FPD-3018
19. Bending tube FPD-3019
20. “U type” bending tube FPD-3020
21. Clamping ring FPD-3021
22. Nut FPD-3022
23. Stub pipe PP-1004
24. O-ring PP-1005
25. Nut 5.8” PP-1006
26. O-ring PP-1003
27. Inlet aperture screw FPD-3027
28. Caseback FPD-3028
29. Rubber foot FPD-3029
30. Foot screw FPD-3030
31. Washer FPD-3031
32. Nut FPD-3032
33. Blind rivet nut FPD-3033
34. Caseback screw FPD-3034
Figure 6 shows all housing components, interior nishing and the tting of its components.
In Table 4 all of the appliance’s components are listed together with their catalogue numbers.
