7. Technical Documentation, Description of Parts. FPD-3000
The construction of the ll station FPD-3000 will be outlined in this section.
The directory and main components are listed here.
The following basic components of the air ll station are shown in Figure 1:
Casing of the lling station with elements of the pneumatic installation (1),
lever valve ZD-3500 (2) and lling hose with female quick release coupler (3)
for the bottle connection.
Figure 4: Basic construction of the ll station FPD-3000.
Table 3. Basic construction of the ll station FPD-3000:
No. Part Catalogue-No.
1. Casing FPD-3001
2. Lever valve ZD-3500
3. Filling hose WP-2000
