Manta FPS-3000 - Pneumatic Installation Set-Up; 8 Storage; 9 Guarantee

Figure 10: Filling hose with female quick release coupler and fuse
7.4 Pneumatic installation set-up
8. Storage
During storage, the appliance and especially the lever valve and lling hoses
should be protected against mechanical damage.
9. Guarantee
The ll station is guaranteed for 24 months by the manufacturer.
Inspection or maintenance work by unauthorised persons, as well as usage of spare parts not
obtained from the manufacturer, will render the guarantee invalid.
Pressure gauge
Connection HP .5.8”
with plug
Lever valve
ZD-3500
Three pin switch
Three pin switch
Connection
HP 5.8”
Female quick
release coupler
16USER MANUAL / FPS-3000 / FPD-3000 / © 2018 MANTA / All rights reserved.
