Manta FPS-3000 - Filling Hose

Table 6. List of hose parts with female quick release coupler and fuse (Figure 9):
No. Part Catalogue-No.
1. Filling hose WP-2001
2. Hose grip WP-1002
3. Washer WP-1003
4. O-Ring ZD-3514
5. Hose Seal ZD-3515
6. O-Ring ZD-3516
7. O-Ring SZ-1002
8. Fuse SZ-1008
9. Fuse Spring SZ-1009
10. Quick Release Coupler SZ-1000
Figure 9: Filling hose with female quick release coupler and fuse
2
3
7
7
8
5
6
7.3. Filling hose
