Table 5. List of lever valve components ZD-3500 (Figure 7):

No. Part Catalogue-No.

1. Valve Body ZD-3501

2. Filter ZD-3502

3. Valve Insert WZ-1000

4. Ram Body ZD-3503

5. Ram ZD-3504

6. Lever Spring ZD-3505

7. Lever ZD-3506

8. Air Flow Adjuster ZD-3507

9. Lever Bolt ZD-3508

10. Lever Boot ZD-3509

11. Ball knob ZD-3511

12. Spring Ring ZD-3512

13. Nut ZD-3513

14. O-Ring ZD-3514

15. Hose Seal ZD-3515

16. O-Ring ZD-3516
