Mantis 3558 User Manual

7Contact us at www.mantis.com
Assembly
1. On/off switch
2. Lock-off button
3. Upper handle
4. Power cord
5. Cord clip
6. Middle handle
7. Upper handle knob and bolt (2)
8. Middle handle knob and bolt (2)
9. Guard
10. Wheels
11. Steel blades
12. Gear box
13. Motor housing
14. Battery
15. Charger
5
13
9
14
7
6
8
4
12
11
15
2
1
3
10
Tiller/Cultivator Parts
1. On/off switch
2. Lock-off button
3. Upper handle
4. Cord clip
5. Middle handle
6. Upper handle knob and bolt (2)
7. Middle handle knob and bolt (2)
8. Fender Guard
9. Wheels
10. Steel Tines (blades)
11. Gear box
12. Motor housing
13. Two speed switch
14. Battery
15. Charger
1
2
3
4
5
6
8
9
10
11
12
14
15
7
13

Mantis 3558 Specifications

General

Brand	Mantis
Model	3558
Category	Tiller
Language	English
