Mantis Edger User Manual

26
MANTIS EDGER PARTS LIST
KEY # PART # DESCRIPTION
33 100217 Blade Cover Lid 34 100218 Wheel 35 100219 Wheel Arm 36 100220 Height Adjustment Pin 37 100221 Handle Height Adjustment 38 100222 Shield Edger Body 39 100529 Screw 5.5mm 41 100223 Wheel Bushing RH 42 100224 Wheel Bushing LH 43 100531 Nut Clutch Drum 44 100225 Handle Right 45 100226 Handle Left 46 100227 Handle Cross Brace 47 100228 Throttle Trigger assembly 48 100532 Handle Clamp 49 100229 Grip Right Handle w/o Throttle 50 100230 Housing Throttle 51 100231 Grip Left Handle 52 100533 Bolt 1/4” x 5.5" 53 100232 Knob 54 100233 Main Shaft 55 100234 Main Body 56 100235 Clutch Housing 57 100236 Dust Plug 58 100702 Instruction Book Mailorder 59 100237 Switch Wire 61 100601 Motor Warning Label 62 100200 Throttle Cable 63 4078 Nut Jam M6 Hex 64 4079 Washer Lock Internal M6 65 380E-4B1E Engine 66 100608 Mantis Edger Label
KEY # PART # DESCRIPTION
1 100500 Screw M5 x 36mm 2 100501 Nut Nyloc 5mm 3 100100 Bearing with seal 12 x 32 x 10 4 100101 “O” ring 64 x 1.75mm 5 9985 Grease 6 100102 Felt Seal 7 100203 Blades, Mantis Edger 8 100108 Blade Drum 9 100109 Blade Shaft Drive
10 100506 Blade Washer Small 11 100507 Blade Washer Large 12 100111 Crown Gear Spacer 13 100602 Warning Label “Blade Cover” (P) 14 100603 Warning Label Handle (P) 15 100513 Nut M12 x 1.75 16 100122 Pinion L/E 17 100515 Screw M5 x 39 S/thread 18 100521 Self Screw Thread M5 x 19 19 100204 Spring Throttle Lock 20 100205 Spring Throttle Trigger 21 100206 Tab Connector 45 degree 22 100534 Washer Pinion .050 23 100208 Gear, Crown 24 100209 Trigger Throttle 25 100210 Throttle Interlock 26 100211 Switch Slide 27 100212 Spring Adj. Arm 28 100528 Washer Wheel Arm 29 100213 Debris Deflector 30 100214 Spring Debris Deflector 31 100215 Debris Deflector Limiter 32 100216 Blade and Bearing Cover
NOTE: Please use the Part No.
when ordering any parts

Mantis Edger Specifications

General

Brand	Mantis
Model	Edger
Category	Edger
Language	English
