Connection example
In this example, the unit with ID set to “Leader” controls the units with
the IDs set to “Member 1”, “Member 2”, or “Member 3”.
0
The MODEL 10 F.C.B.S. function is only valid between the same MODEL 10
models.
0
If you want to power on multiple amplifiers connected to the F.C.B.S., please
turn on the power in the order of “Leader” - “Member 1” - “Member 2” -
“Member 3”. When turning off the power, turn them off in the reverse order.
Signal flow
Leader
Member 1
Member 2
Member 3
