29
110/220V
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST, /
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
002B 4822 459 05285 FRONT PANEL 355K248110
003B 4822 426 10823 ESCUTCHEON, FRONT SIDE
PIECE LEFT GLD
355K063110
004B 4822 426 10824 ESCUTCHEON, FRONT SIDE
PIECE RIGHT GLD
355K063120
007B 4822 454 13454 BADGE, META-LETTER
MARANTZ SILVER
208J251010
010B 4822 463 11251 BUSHING, POWER BUTTON 355K259040
013B 4822 492 71359 SPRING, RETAINER BUTTON
GROUND
270K115030
015B 4822 463 11252 RETAINER, BUSH BUTTON
PLAY STOP PAUSE
355K104120
017B 4822 532 40221 RETAINER, BUSH BUTTON
OPEN/CLOSE
270K104010
020B 4822 410 12398 BUTTON, ASSY PLAY GLD 355K270520
030B 4822 410 12399 BUTTON, ASSY STOP GLD 355K270530
040B 4822 410 12401 BUTTON, ASSY PAUSE GLD 355K270540
050B 4822 410 12402 BUTTON ASSY, OPEN/CLOSE 355K270550
060B 4822 492 71357 SPRING, BUTTON LARGE 270K115010
061B 4822 462 71931 BUFFER, 270K056010
070B 4822 463 11253 BUSHING, FILTER
BUTTON/LED
355K259020
075B 4822 463 11254 BUSHING, TRACK BUTTON 355K259030
080B 4822 410 12403 BUTTON, FILTER 355K270170
085B 4822 410 12404 BUTTON, TRACK 355K270160
096B 4822 450 10643 WINDOW, GLASS,PINK
SMOKE
355K158010
130B 4822 410 12405 BUTTON, POWER ASSY GLD 355K270510
146B 4822 442 01801 ESCUTCHEON, TRAY LID
GLASS
355K063030
001D LID, TOP COVER 355K257110
002D ESCUTCHEON, LOUVER TOP
COVER GLD
231J063110
020D SIDE PANEL, LEFT GLD 355K249110
021D SIDE PANEL, RIGHT GLD 355K249120
024D 4822 454 30488 ESCUTCHEON, SIDE PANEL 270K063050
028G 4822 402 11299 LINK, POWER SW. LINK 355K121010
095G 4822 462 42132 LEG, U D60 163J057220
100G SCREW, 001G + A001 PIVOT 355K010010
A001 4822 691 10787 LOADER ASSY VAM1252 355K304520
J001 4822 265 11399 JACK, 2P AC INLET SOT-16C YJ04002360
J081 K 4822 265 10092 JACK, AC ADAPTER.SMK
S-16116
YJ04001240
L001 F MAINS TRANSFORMER 100V TS46010010
L001 K MAINS TRANSFORMER
110/220V
TS46010040
L001 /02 4822 146 11139 MAINS TRANSFORMER 230V TS46010020
L002 F SUB TRANSFORMER 100V TS13521010
L002 K SUB TRANSFORMER TS13521040
L002 /02 4822 146 11141 SUB TRANSFORMER 230V TS13521020
L003 FERRITE CORE,
TFCK-23-11-14
FC50230010
L004 FERRITE CORE,
HF70SH28X2X10
FC90280010
L005 F FERRITE CORE,
ZCAT1518-0730
FC50150020
L006 F FERRITE CORE,
ZCA1518-0730
FC50150020
W001 F 4822 321 11337 MAINS CORD, 125V ZC01802080
W001 K MAINS CORD, 2.5A 250V ZC01803090
W001 /02 4822 321 11439 MAINS CORD, 10A 250V ZC01803080
PACKING
001T F USER GUIDE 355K851110
001T K USER GUIDE 355K851350
001T /02 4822 736 16822 USER GUIDE 355K851310
Z003 4822 219 10702 REMOTE COMMANDER,
RC-D7CD
ZK355K0010
NOT STANDARD SPARE
PARTS
001S PACKING CASE, HI-FI GL 355K801020
002S CUSHION, FRONT 270K809010
003S CUSHION, REAR 270K809020
009S PROTECTOR, COVER 355K269010
Z001 BATTERY, UM-4NEPH/2S ZF24302000
Z002 CONNECTIVE CORD,
RCA CABLE ASSY
ZD01000680
