15. ELECTRICAL PARTS LIST
The suppliers and their type numbers of fusible resistors
are as follows;
1. KOA Corporation
Part No. (MJI) Type No. (KOA) Description
NH05 × × × 140 RF25S × × × × ΩJ(±5% 1/4W)
NH05 × × × 120 RF50S × × × × ΩJ(±5% 1/2W)
NH85 × × × 110 RF73B2A × × × × ΩJ(±5% 1/10W)
NH95 × × × 140 RF73B2E × × × × ΩJ(±5% 1/4W)
2. Matsushita Electronic Components Co., Ltd
Part No. (MJI) Type No. (MEC) Description
NF05 × × × 140 ERD-2FCJ × × × (±5% 1/4W)
RF05 × × × 140
NF02 × × × 140
ERD-2FCG
× × × (±2% 1/4W)
RF02 × × × 140
Examples ;
Resistance value
0.1 Ω.... 001 10 Ω .... 100 1 kΩ .... 102 100 kΩ.... 104
0.5 Ω.... 005 18 Ω .... 180 2.7 kΩ ....272 680 kΩ.... 684
1 Ω.... 010 100 Ω .... 101 10 kΩ .... 103 1 MΩ .... 105
6.8 Ω.... 068 390 Ω .... 391 22 kΩ .... 223 4.7 MΩ.... 475
ASSIGNMENT OF COMMON PARTS CODES.
RESISTORS
R
: 1) GD05 × × × 140, Carbon film fixed resistor, ±5% 1/4W
R
: 2) GD05 × × × 160, Carbon film fixed resistor, ±5% 1/6W
Examples ;
Resistance value
0.1 Ω.... 001 10 Ω .... 100 1 kΩ .... 102 100 kΩ.... 104
0.5 Ω.... 005 18 Ω .... 180 2.7 kΩ .... 272 680 kΩ.... 684
1 Ω.... 010 100 Ω .... 101 10 kΩ .... 103 1 MΩ.... 105
6.8 Ω.... 068 390 Ω .... 391 22 kΩ .... 223 4.7 MΩ.... 475
Note : Please distinguish 1/4W from 1/6W by the shape of parts
used actually.
CAPACITORS
C
: CERAMIC CAP.
3) DD1 × × × × 370, Ceramic capacitor
Disc type
Temp.coeff.P350 N1000, 50V
Examples ;
Tolerance (Capacity deviation)
±0.25 pF .... 0
±0.5 pF .... 1
±5% .... 5
Tolerance of COMMON PARTS handled here are as follows :
0.5 pF 5 pF .... ±0.25 pF
6 pF 10 pF .... ±0.5 pF
12 pF 560 pF .... ±5%
Capacity value
0.5 pF .... 005 3 pF .... 030 100 pF .... 101
1 pF .... 010 10 pF .... 100 220 pF .... 221
1.5 pF .... 015 47 pF .... 470 560 pF .... 561
C
: CERAMIC CAP.
4) DK16 × × × 300, High dielectric constant ceramic
capacitor
Disc type
Temp.chara. 2B4, 50V
Examples ;
Capacity value
100 pF .... 101 1000 pF .... 102 10000 pF .... 103
470 pF .... 471 2200 pF .... 222
C
: 5) ELECTROLY CAP. ( ), 6) FILM CAP. ( )
5) EA × × × × × × 10, Electrolytic capacitor
One-way lead type, Tolerance ±20%
Examples ;
Capacity value
0.1 µF .... 104 4.7 µF .... 475 100 µF....107
0.33 µF .... 334 10 µF .... 106 330 µF ....337
1 µF .... 105 22 µF ....226 1100 µF .... 118
2200 µF ....228
Working voltage
6.3V .... 006 25V .... 025
10V .... 010 35V .... 035
16V .... 016 50V .... 050
6) DF15 × × × 350 Plastic film capacitor
DF15 × × × 310 One-way type, Mylar ±5% 50V
DF16 × × × 310 Plastic film capacitor
One-way type, Mylar ±10% 50V
Examples ;
Capacity value
0.001 µF (1000 pF) ....... 102 0.1 µF .... 104
0.0018 µF ........................ 182 0.56 µF.... 564
0.01 µF ........................ 103 1 µF....105
0.015 µF ........................ 153
: 1) The above CODES ( R , R , C , C
and
C ) are omitted on the schematic diagram in some
case.
2) On the occasion, be confirmed the common parts on
the parts list.
3) Refer to “Common Parts List” for the other common
parts (RI05, DD4, DK4).
➀
➁
Capacity value
Tolerance
➃
Capacity value
Resistance value
➄
Working voltage
Capacity value
➆
Capacity value
NOTE
NOTE ON SAFETY FOR FUSIBLE RESISTOR :
Resistance value
Resistance value
(0.1 Ω − 10 kΩ)
Resistance value
Resistance value
ANT. : ANTENNA BATT. : BATTERY
CAP. : CAPACITOR CER. : CERAMIC
CONN. : CONNECTING DIG. : DIGITAL
HP : HEADPHONE MIC. : MICROPHONE
µ-PRO : MICROPROCESSOR REC. : RECORDING
RES. : RESISTOR SPK : SPEAKER
SW : SWITCH TRANSF. : TRANSFORMER
TRIM. : TRIMMING TRS. : TRAMSISTOR
VAR. : VARIABLE X’TAL : CRYSTAL
安全上の注意安全上の注意
安全上の注意安全上の注意
安全上の注意
::
::
:
がついている部品は、安全上重要な部品です。必ず
指定されている部品番号の部品を使用して下さい。
SM970926ACT
ABBREVIATION AND MARKS
{
{
{
{
{
{
{
{
{
{
➂
➀
➁
➂
➃
➄
➅
➆
➅
NOTE ON SAFETY :
Symbol Fire or electrical shock hazard. Only original
parts should be used to replaced any part marked with
symbol . Any other component substitution (other
than original type), may increase risk of fire or electrical
shock hazard.
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST, /
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PA16-DAC/HDAM
CIRCUIT BOARD
PA16-CAPACITORS
CD01 4822 124 41539 ELECT 47µF ±20% 16V OA47601620
CD02 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD03 F FILM 680pF ±5% 100V CHIP OF55681540
CD03 K /02 4822 121 70319 FILM 470pF ±5% 50V OF15471030
CD05
4822 121 10867 FILM 0.1µF ±5% 100V CHIP OF55104540
CD18
CD19 4822 126 12061 CER. 0.1µ F ±10% 25V CHIP DK56104200
CD20 F 4822 124 22238 ELECT 100µF 25V OA10702550
CD20 K /02 4822 124 80119 ELECT 100µF 25V OA10702540
CD21 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD22 4822 124 22238 ELECT 100µF 25V OA10702550
CD23 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD24 4822 124 22238 ELECT 100µF 25V OA10702550
CD27 4822 123 30361 MICA 56pF 500WV CHIP DF95560500
CD28 4822 126 14578 MICA 1200pF 100WV CHIP DF95122510
CD29 4822 126 14579 MICA 1000pF 100WV CHIP DF95102510
CD37 4822 123 30361 MICA 56pF 500WV CHIP DF95560500
CD38 4822 126 14578 MICA 1200pF 100WV CHIP DF95122510
CD39 4822 126 14579 MICA 1000pF 100WV CHIP DF95102510
CD51 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD53 F FILM 680pF ±5% 100V CHIP OF55681540
CD53 K /02 4822 121 70319 FILM 470pF ±5% 50V OF15471030
CD55
4822 121 10867 FILM 0.1µF ±5% 100V CHIP OF55104540
CD68
CD69 4822 126 12061 CER. 0.1µF ±10% 25V CHIP DK56104200
CD70 F 4822 124 22238 ELECT 100µF 25V OA10702550
CD70 K /02 4822 124 80119 ELECT 100µF 25V OA10702540
CD71 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD72 4822 124 22238 ELECT 100µF 25V OA10702550
CD73 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
CD74 4822 124 22238 ELECT 100µF 25V OA10702550
CD77 4822 123 30361 MICA 56pF 500WV CHIP DF95560500
CD78 4822 126 14578 MICA 1200pF 100WV CHIP DF95122510
CD79 4822 126 14579 MICA 1000pF 100WV CHIP DF95102510
CD87 4822 123 30361 MICA 56pF 500WV CHIP DF95560500
CD88 4822 126 14578 MICA 1200pF 100WV CHIP DF95122510
CD89 4822 126 14579 MICA 1000pF 100WV CHIP DF95102510
C401 4822 126 14578 MICA 1200pF 100WV CHIP DF95122510
C402 4822 126 14579 MICA 1000pF 100WV CHIP DF95102510
C403 4822 126 14579 MICA 1000pF 100WV CHIP DF95102510
C405 4822 123 30361 MICA 56pF 500WV CHIP DF95560500
C407 F 4822 124 22242 ELECT 470µF 25V OA47702550
C407 K /02 4822 124 80958 ELECT 470µF 16V OA47701640
C408 F 4822 124 22242 ELECT 470µF 25V OA47702550
C408 K /02 4822 124 80958 ELECT 470µF 16V OA47701640
C421 4822 126 14578 MICA 1200pF 100WV CHIP DF95122510
C422 4822 126 14579 MICA 1000pF 100WV CHIP DF95102510
C423 4822 126 14579 MICA 1000pF 100WV CHIP DF95102510
C425 4822 123 30361 MICA 0.1µF +-80%-20% CHIP DF95560500
C427 F 4822 124 22242 ELECT 470µF 25V OA47702550
C427 K /02 4822 124 80958 ELECT 470µF 16V OA47701640
C428 F 4822 124 22242 ELECT 470µF 25V OA47702550
C428 K /02 4822 124 80958 ELECT 470µF 16V OA47701640
C451 4822 126 14578 MICA 1200pF 100WV CHIP DF95122510
C452 4822 126 14579 MICA 1000pF 100WV CHIP DF95102510
C453 4822 126 14579 MICA 1000pF 100WV CHIP DF95102510
C455 4822 123 30361 MICA 56pF 500WV CHIP DF95560500
C457 F 4822 124 22242 ELECT 470µF 25V OA47702550
C457 K /02 4822 124 80958 ELECT 470µF 16V OA47701640
C458 F 4822 124 22242 ELECT 470µF 25V OA47702550
C458 K /02 4822 124 80958 ELECT 470µF 16V OA47701640
C471 4822 126 14578 MICA 1200pF 100WV CHIP DF95122510
C472 4822 126 14579 MICA 1000pF 100WV CHIP DF95102510
C473 4822 126 14579 MICA 1000pF 100WV CHIP DF95102510
C475 4822 123 30361 MICA 56pF 500WV CHIP DF95560500
C477 F 4822 124 22242 ELECT 470µF 25V OA47702550
C477 K /02 4822 124 80958 ELECT 470µF 16V OA47701640
C478 F 4822 124 22242 ELECT 470µF 25V OA47702550
C478 K /02 4822 124 80958 ELECT 470µF 16V OA47701640
C602 4822 123 30361 MICA 56pF 500WV CHIP DF95560500
C603 4822 123 30422 MICA 33pF 500WV CHIP DF95330500
C604 4822 124 80123 ELECT 220µF 16V OA22701640
C605 4822 124 80123 ELECT 220µF 16V OA22701640
C606 4822 126 11759 CER. 100pF ±5% 50V CHIP DD95101300
C611 F 4822 124 22242 ELECT 470µF 25V OA47702550
C611 K /02 4822 124 80958 ELECT 470µF 16V OA47701640
C612 F 4822 124 22242 ELECT 470µF 25V OA47702550
C612 K /02 4822 124 80958 ELECT 470µF 16V OA47701640
C632 4822 123 30361 MICA 56pF 500WV CHIP DF95560500
C633 4822 123 30422 MICA 33pF 500WV CHIP DF95330500
C634 4822 124 80123 ELECT 220µF 16V OA22701640
C635 4822 124 80123 ELECT 220µF 16V OA22701640
C636 4822 126 11759 CER. 100pF ±5% 50V CHIP DD95101300
C637 F 4822 124 22242 ELECT 470µF 25V OA47702550
C637 K /02 4822 124 80958 ELECT 470µF 16V OA47701640
C638 F 4822 124 22242 ELECT 470µF 25V OA47702550
C638 K /02 4822 124 80958 ELECT 470µF 16V OA47701640
C702 4822 123 30361 MICA 56pF 500WV CHIP DF95560500
C703 4822 123 30422 MICA 33pF 500WV CHIP DF95330500
C704 4822 124 80123 ELECT 220µF 16V OA22701640
C705 4822 124 80123 ELECT 220µF 16V OA22701640
C712 4822 123 30361 MICA 56pF 500WV CHIP DF95560500
C713 4822 123 30422 MICA 33pF 500WV CHIP DF95330500
C714 4822 124 80123 ELECT 220µF 16V OA22701640
C715 4822 124 80123 ELECT 220µF 16V OA22701640
C716 4822 126 11759 CER. 100pF ±5% 50V CHIP DD95101300
C717 4822 126 11759 CER. 100pF ±5% 50V CHIP DD95101300
C721 F 4822 124 22242 ELECT 470µF 25V OA47702550
C721 K /02 4822 124 80958 ELECT 470µF 16V OA47701640
C722 F 4822 124 22242 ELECT 470µF 25V OA47702550
C722 K /02 4822 124 80958 ELECT 470µF 16V OA47701640
C736 4822 126 11759 CER. 100pF ±5% 50V CHIP DD95101300
C737 4822 126 11759 CER. 100pF ±5% 50V CHIP DD95101300
C752 4822 123 30361 MICA 56pF 500WV CHIP DF95560500
C753 4822 123 30422 MICA 33pF 500WV CHIP DF95330500
C754 4822 124 80123 ELECT 220µF 16V OA22701640
C755 4822 124 80123 ELECT 220µF 16V OA22701640
C756 F 4822 124 22242 ELECT 470µF 25V OA47702550
C756 K /02 4822 124 80958 ELECT 470µF 16V OA47701640
C757 F 4822 124 22242 ELECT 470µF 25V OA47702550
C757 K /02 4822 124 80958 ELECT 470µF 16V OA47701640
C772 4822 123 30361 MICA 56pF 500WV CHIP DF95560500
C773 4822 123 30422 MICA 3pF 500WV CHIP DF95330500
C774 4822 124 80123 ELECT 220µF 16V OA22701640
C775 4822 124 80123 ELECT 220µF 16V OA22701640
PA16-RESISTORS
RD11 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
RD12 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
RD13 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
RD14 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
RD15 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
RD16 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
RD17 4822 116 83229 33kΩ ±1% 1/10W CHIP NI01333110
RD18 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
RD19 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
RD20 10.0Ω ±1% 1/4W GM114100G0
RD21 10.0Ω ±1% 1/4W GM114100G0
RD22 1.62kΩ ±1% 1/4W GM11416210
RD31 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
RD32 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
