Marantz 74 CD7 - Exploded View and Parts List; K Version Parts; Loader and Front Panel Assemblies

43
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST, /
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
RD33 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
RD34 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
RD35 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
RD36 4822 111 90893 100Ω±5% 1/10W CHIP NI05101110
RD37 4822 116 83229 33kΩ ±1% 1/10W CHIP NI01333110
RD38 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
RD39 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
RD40 10.0Ω ±1% 1/4W GM114100G0
RD41 10.0Ω ±1% 1/4W GM114100G0
RD42 1.62kΩ ±1% 1/4W GM11416210
RD51 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
RD52 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
RD53 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
RD54 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
RD55 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
RD56 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
RD57 4822 116 83229 33kΩ ±1% 1/10W CHIP NI01333110
RD58 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
RD59 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
RD60 10.0Ω ±1% 1/4W GM114100G0
RD61 10.0Ω ±1% 1/4W GM114100G0
RD62 1.62kΩ ±1% 1/4W GM11416210
RD81 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
RD82 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
RD83 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
RD84 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
RD85 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
RD86 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
RD87 4822 116 83229 33kΩ±1% 1/10W CHIP NI01333110
RD88 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
RD89 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
RD90 10.0Ω ±1% 1/4W GM114100G0
RD91 10.0Ω ±1% 1/4W GM114100G0
RD92 1.62kΩ ±1% 1/2W GM11416210
R401 1.47kΩ ±1% 1/4W GM11414710
R402 3.01kΩ ±1% 1/4W GM11430110
R404 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R405 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R406 4822 111 90893 100Ω±5% 1/10W CHIP NI05101110
R407 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
R408 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R409 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R410 4822 116 83229 33kΩ ±1% 1/10W CHIP NI01333110
R411 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
R412 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R413 10.0Ω ±1% 1/4W GM114100G0
R414 10.0Ω±1% 1/4W GM114100G0
R421 1.47kΩ ±1% 1/4W GM11414710
R422 3.01kΩ ±1% 1/4W GM11430110
R424 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R425 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R426 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R427 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
R428 4822 111 90893 100Ω +-5% 1/10W CHIP NI05101110
R429 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R430 4822 116 83229 33kΩ ±1% 1/10W CHIP NI01333110
R431 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
R432 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R433 10.0Ω ±1% 1/4W GM114100G0
R434 10.0Ω ±1% 1/4W GM114100G0
R451 1.47kΩ ±1% 1/4W GM11414710
R452 3.01kΩ ±1% 1/4W GM11430110
R454 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R455 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R456 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R457 4822 116 83352 560 Ω ±5% 1/10W CHIP NI05561110
R458 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R459 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R460 4822 116 83229 33kΩ ±1% 1/10W CHIP NI01333110
R461 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
R462 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R463 10.0Ω ±1% 1/4W GM114100G0
R464 10.0Ω ±1% 1/4W GM114100G0
R471 1.47kΩ ±1% 1/4W GM11414710
R472 3.01kΩ±1% 1/4W GM11430110
R474 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R475 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R476 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R477 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
R478 4822 111 90893 100Ω±5% 1/10W CHIP NI05101110
R479 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R480 4822 116 83229 33kΩ ±1% 1/10W CHIP NI01333110
R481 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
R482 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R483 10.0Ω ±1% 1/4W GM114100G0
R484 10.0Ω ±1% 1/4W GM114100G0
R601 4822 111 90885 2.7kΩ ±1% 1/10W CHIP NI01272110
R602 4822 116 83253 1.5kΩ ±1% 1/10W CHIP NI01152110
R603 4822 111 90885 2.7kΩ ±1% 1/10W CHIP NI01272110
R604 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R605 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R606 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R608 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
R609 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R610 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R611 4822 116 83229 33kΩ ±1% 1/10W CHIP NI01333110
R612 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
R613 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R614 10.0Ω ±1% 1/4W GM114100G0
R615 10.0Ω ±1% 1/4W GM114100G0
R616 4822 116 83253 1.5kΩ ±1% 1/10W CHIP NI01152110
R618 4822 111 20407 100.0Ω ±1% 1/4W NR01101140
R619 10kΩ ±1% 1/4W GM11410020
R620 4822 111 90896 100kΩ ±5% 1/10W CHIP NI05104110
R631 4822 111 90885 2.7kΩ ±1% 1/10W CHIP NI01272110
R632 4822 116 83253 1.5kΩ ±1% 1/10W CHIP NI01152110
R633 4822 111 90885 2.7kΩ ±1% 1/10W CHIP NI01272110
R634 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R635 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R636 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R638 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
R639 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R640 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R641 4822 116 83229 33kΩ ±1% 1/10W CHIP NI01333110
R642 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
R643 4822 111 90893 100Ω±5% 1/10W CHIP NI05101110
R644 10.0Ω ±1% 1/4W GM114100G0
R645 10.0Ω ±1% 1/4W GM114100G0
R646 4822 116 83253 1.5kΩ ±1% 1/10W CHIP NI01152110
R648 4822 111 20407 100.0Ω±1% 1/4W NR01101140
R649 10kΩ ±1% 1/4W GM11410020
R650 4822 111 90896 100kΩ ±5% 1/10W CHIP NI05104110
R701 4822 116 83255 3.3kΩ ±1% 1/10W CHIP NI01332110
R702 4822 116 83253 1.5kΩ ±1% 1/10W CHIP NI01152110
R703 4822 116 83255 3.3kΩ ±1% 1/10W CHIP NI01332110
R704 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R705 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R706 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R707 4822 116 83255 3.3kΩ ±1% 1/10W CHIP NI01332110
R708 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
R709 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R710 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R711 4822 116 83229 33kΩ ±1% 1/10W CHIP NI01333110
R712 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
