Marantz 74 CD7 - Parts List Symbol Key

44
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST, /
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
R713 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R714 10.0Ω±1% 1/4W GM114100G0
R715 10.0Ω ±1% 1/4W GM114100G0
R716 4822 116 83253 1.5kΩ ±1% 1/10W CHIP NI01152110
R717 4822 116 83229 33kΩ ±1% 1/10W CHIP NI01333110
R718 4822 111 20407 100.0Ω ±1% 1/4W NR01101140
R719 10kΩ ±1% 1/4W GM11410020
R720 4822 111 90896 100kΩ ±5% 1/10W CHIP NI05104110
R721 4822 116 83255 3.3kΩ ±1% 1/10W CHIP NI01332110
R722 4822 116 83253 1.5kΩ ±1% 1/10W CHIP NI01152110
R723 4822 116 83255 3.3kΩ ±1% 1/10W CHIP NI01332110
R724 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R725 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R726 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R727 4822 116 83255 3.3kΩ ±1% 1/10W CHIP NI01332110
R728 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
R729 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R730 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R731 4822 116 83229 33kΩ ±1% 1/10W CHIP NI01333110
R732 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
R733 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R734 10.0Ω ±1% 1/4W GM114100G0
R735 10.0Ω ±1% 1/4W GM114100G0
R736 4822 116 83253 1.5kΩ±1% 1/10W CHIP NI01152110
R737 4822 116 83229 33kΩ ±1% 1/10W CHIP NI01333110
R738 4822 111 20407 100.0Ω ±1% 1/4W NR01101140
R739 10kΩ±1% 1/4W GM11410020
R740 4822 111 90896 100kΩ ±5% 1/10W CHIP NI05104110
R751 4822 116 83255 3.3kΩ ±1% 1/10W CHIP NI01332110
R752 4822 116 83253 1.5kΩ ±1% 1/10W CHIP NI01152110
R753 4822 116 83255 3.3kΩ ±1% 1/10W CHIP NI01332110
R754 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R755 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R756 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R757 4822 116 83255 3.3kΩ±1% 1/10W CHIP NI01332110
R758 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
R759 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R760 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R761 4822 116 83229 33kΩ ±1% 1/10W CHIP NI01333110
R762 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
R763 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R764 10.0Ω ±1% 1/4W GM114100G0
R765 10.0Ω ±1% 1/4W GM114100G0
R766 4822 116 83253 1.5kΩ ±1% 1/10W CHIP NI01152110
R767 4822 116 83229 33kΩ ±1% 1/10W CHIP NI01333110
R768 4822 111 20407 100.0Ω±1% 1/4W NR01101140
R769 10kΩ ±1% 1/4W GM11410020
R770 4822 111 90896 100kΩ ±5% 1/10W CHIP NI05104110
R771 4822 116 83255 3.3kΩ ±1% 1/10W CHIP NI01332110
R772 4822 116 83253 1.5kΩ ±1% 1/10W CHIP NI01152110
R773 4822 116 83255 3.3kΩ ±1% 1/10W CHIP NI01332110
R774 4822 116 90503 150Ω ±5% 1/10W CHIP NI05151110
R775 4822 116 90503 150Ω±5% 1/10W CHIP NI05151110
R776 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R777 4822 116 83255 3.3kΩ ±1% 1/10W CHIP NI01332110
R778 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
R779 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R780 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R781 4822 116 83229 33kΩ ±1% 1/10W CHIP NI01333110
R782 4822 116 83352 560Ω ±5% 1/10W CHIP NI05561110
R783 4822 111 90893 100Ω ±5% 1/10W CHIP NI05101110
R784 10.0Ω ±1% 1/4W GM114100G0
R785 10.0Ω ±1% 1/4W GM114100G0
R786 4822 116 83253 1.5kΩ ±1% 1/10W CHIP NI01152110
R787 4822 116 83229 33kΩ ±1% 1/10W CHIP NI01333110
R788 4822 111 20407 100.0Ω ±1% 1/4W NR01101140
R789 10kΩ±1% 1/4W GM11410020
R790 4822 111 90896 100kΩ ±5% 1/10W CHIP NI05104110
PA16-SEMICONDUCTORS
DD01 4822 130 80318 ZENER DIODE
RD6.8JB2 MTZJ6.8C
HD30681000
DD02 4822 130 32362 DIODE 1SS176 MA165
1SS254 30V 0.1A
HD20002000
DD03 4822 130 81148 CHIP DIODE IMN10 HZ20007210
DD04 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
DD13 4822 130 81148 CHIP DIODE IMN10 HZ20007210
DD14 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
DD53 4822 130 81148 CHIP DIODE IMN10 HZ20007210
DD54 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
DD73 4822 130 81148 CHIP DIODE IMN10 HZ20007210
DD74 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
D403 4822 130 81148 CHIP DIODE IMN10 HZ20007210
D404 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
D413 4822 130 81148 CHIP DIODE IMN10 HZ20007210
D414 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
D453 4822 130 81148 CHIP DIODE IMN10 HZ20007210
D454 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
D473 4822 130 81148 CHIP DIODE IMN10 HZ20007210
D474 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
D601 4822 130 32362 DIODE 1SS176 MA165
1SS254 30V 0.1A
HD20002000
D602 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
D603 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
D605 4822 130 32362 DIODE 1SS176 MA165
1SS254 30V 0.1A
HD20002000
D631 4822 130 32362 DIODE 1SS176 MA165
1SS254 30V 0.1A
HD20002000
D632 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
D633 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
D703 4822 130 81148 CHIP DIODE IMN10 HZ20007210
D704 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
D713 4822 130 81148 CHIP DIODE IMN10 HZ20007210
D714 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
D753 4822 130 81148 CHIP DIODE IMN10 HZ20007210
D754 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
D773 4822 130 81148 CHIP DIODE IMN10 HZ20007210
D774 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
QD01 4822 130 11604 TRS. 2SB1020A HT21020100
QD03 4822 209 17426 IC TDA1541A/N2/S2 16BIT HC10083490
QD04 4822 130 42843 F.E.T. 2SK389 GR BL HF203892A0
QD05 4822 130 61425 CHIP TRS. 2SC2873 Y HX328731B0
QD06 4822 130 63928 CHIP TRS. 2SA1312 B HX113121B0
QD07 4822 130 63928 CHIP TRS. 2SA1312 B HX113121B0
QD08 4822 130 63929 CHIP TRS. 2SC3324 B HX333241B0
QD09 5322 130 41844 F.E.T. 2SK170 V HF201701H0
QD10 4822 130 62649 F.E.T. 2SJ74 V HF100741H0
QD14 4822 130 42843 F.E.T. 2SK389 GR BL HF203892A0
QD15 4822 130 61425 CHIP TRS. 2SC2873 Y HX328731B0
QD16 4822 130 63928 CHIP TRS. 2SA1312 B HX113121B0
QD17 4822 130 63928 CHIP TRS. 2SA1312 B HX113121B0
QD18 4822 130 63929 CHIP TRS. 2SC3324 B HX333241B0
QD19 5322 130 41844 F.E.T. 2SK170 V HF201701H0
QD20 4822 130 62649 F.E.T. 2SJ74 V HF100741H0
QD21 4822 209 32984 IC TC7SHU04F HC10427050
QD22 4822 209 61494 IC 74HC74 FLAT HC707400Z0
QD51 4822 209 32984 IC TC7SHU04F HC10427050
QD52 4822 209 61494 IC 74HC74 FLAT HC707400Z0
QD53 4822 209 17426 IC TDA1541A/N2/S2 16BIT HC10083490
QD54 4822 130 42843 F.E.T. 2SK389 GR BL HF203892A0
QD55 4822 130 61425 CHIP TRS. 2SC2873 Y HX328731B0
QD56 4822 130 63928 CHIP TRS. 2SA1312 B HX113121B0
