Front Layout / Middle Layout / Rear Layout
Set the speaker layout when installing 2 sets (4-channels) or more of Height, Ceiling or Dolby Atmos Enabled speakers.
The layouts that can be selected differ depending on the combinations of “Assign Mode” and “Floor” - “Layout” in the menu. (“Assign
Mode” (v p. 222), “Floor” - “Layout” (v p. 223))
Settings AUDIO OUT connectors
Height Sp Dolby Sp NOTE Front Layout Middle Layout Rear Layout HEIGHT 1 HEIGHT 2 HEIGHT 3
2ch 2ch
Front Dolby - Top Rear Front Dolby Top Rear -
Front Dolby - Rear Height Front Dolby Rear Height -
Front Height - Surround Dolby Front Height Surround Dolby -
Front Height -
Back Dolbyz1
Front Height Back Dolby -
Top Front - Surround Dolby Top Front Surround Dolby -
Top Front -
Back Dolbyz1
Top Front Back Dolby -
4ch None
Front Height - Top Middle Front Height Top Middle -
Front Height - Top Rear Front Height Top Rear -
Front Height -
Rear Heightz2
Front Height Rear Height -
Front Height - Surr. Height Front Height Surr. Height -
Top Front - Top Rear Top Front Top Rear -
Top Front - Rear Height Top Front Rear Height -
Top Middle - Rear Height Top Middle Rear Height -
