Speaker configuration and “Amp Assign” settings
This system configuration plays back 13-channels. You can create speaker systems such as a bi-amp connection by changing the “Amp Assign” settings.
Perform “Amp Assign” settings to suit the speaker configuration to be installed. (v p. 222)
Playback speaker in MAIN ZONE “Amp Assign” settings Connection page
5.1-channel playback 13.1ch (Default) 52
7.1-channel playback 13.1ch (Default) 53
9.1-channel playback 13.1ch (Default) 58
13.1-channel playback 13.1ch (Default) 67
13.1-channel playback (Dolby Atmos and Auro-3D) 13.1ch (Default) 72
11.1-channel playback (bi-amp connection of front speakers) 11.1ch (Bi-Amp) 78
11.1-channel playback + second pair of front speakers 11.1ch + Front B 79
The sound mode that can be selected varies according to the speaker configuration.
The following pages provide basic connection examples.
