Example connections when using ceiling
speakers
This 7.1-channel surround system is the same as a basic 5.1-channel
system but with ceiling speakers.
.
C
FL FR
SW
SL SR
TML TMR
0
Set “Floor” - “Layout” to “5ch” and “Height Sp” to “2ch” in the menu when
connecting in this configuration. (v p. 223)
0
The top front or top rear speakers can be connected instead of the top middle
speakers. In this case, set the ceiling speakers to be connected under “Height” -
“Layout” in the menu. (v p. 225)
