Connecting the BALANCED XLR IN connector
This unit is equipped with BALANCED XLR IN connectors. Use these connectors if your device has an XLR connector as an audio output connector.
When using BALANCED XLR IN connectors, assign “XLR” for “Input Assign” – “ANALOG”. (v p. 207)
By default, these connectors are disabled.
G AV8805 BALANCED XLR IN connector PIN arrangement H
.
A
GND (Ground)
B
HOT (+)
C
COLD (–)
