52
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
FRONT PWB
(
CUP11984-1
)
FRONT BK21 ns
p
ns
p
BRACKET FOR DISPLAY UNIT CMD1A374
FRONT BK22 ns
p
ns
p
BRACKET FOR DISPLAY UNIT CMD1A374
FRONT BN22 ns
p
ns
p
CORD WIRE ASSY CWB1C905100EN
FRONT C202 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
FRONT C203 00MEJ47601640 00MEJ47601640 ELECT CAP. 47 UF 16V KS CCEA1CKS470T
FRONT C204 00MEJ47601640 00MEJ47601640 ELECT CAP. 47 UF 16V KS CCEA1CKS470T
FRONT C208 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
FRONT C209 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
FRONT CN21 ns
p
ns
p
CONN. 15P FFC WAFER CJP15GA117ZY
FRONT CN94 ns
p
ns
p
CONN. 7P FFC WAFER CJP07GA117ZY
FRONT D202 90M-HI101120R 90M-HI101120R LED SLR325VRA47 KVDSLR325VRA47
FRONT D203 90M-HI101120R 90M-HI101120R LED SLR325VRA47 KVDSLR325VRA47
FRONT D204 90M-HI101120R 90M-HI101120R LED SLR325VRA47 KVDSLR325VRA47
FRONT F201 90M-HQ300610R 90M-HQ300610R DISPLAY FL DISPLAY FOR CD5400 CFLHCA12SS18T
FRONT IC21 90M-HC700550R 90M-HC700550R IC TC74HCU04AFNG HVI74HCU04AFNG
FRONT J201 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
FRONT J203 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
FRONT J204 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
FRONT J205 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
FRONT J206 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
FRONT J207 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
FRONT J208 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
FRONT J209 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
FRONT J210 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
FRONT J211 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
FRONT J212 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
FRONT J213 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
FRONT J214 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
FRONT J215 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
FRONT J216 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
FRONT J217 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
FRONT J218 ns
p
ns
p
CORD SN95/PB5 0.6 C3A206
FRONT L201 90M-FN000090R 90M-FN000090R EMI FILTER BEAD KLZ9H001Z
FRONT L202 90M-FN000090R 90M-FN000090R EMI FILTER BEAD KLZ9H001Z
FRONT L203 90M-FN000090R 90M-FN000090R EMI FILTER BEAD KLZ9H001Z
FRONT Q202 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
FRONT Q203 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
FRONT Q204 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
FRONT R204 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
FRONT R205 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
FRONT R206 ns
p
ns
p
RES. 1.8K OHM 1/5W J CRD20TJ182T
FRONT R207 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152T
FRONT R208 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
FRONT R209 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
FRONT R210 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
FRONT R216 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
FRONT R217 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
FRONT R218 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
FRONT RS21 00MHW10004210 00MHW10004210 PHOTO UNIT RPM6936-V4 BRVRPM6936V4
FRONT S202 90M-SP001400R 90M-SP001400R PUSH SW TACT SW EVQ22505R CST1A023ZT
FRONT S203 90M-SP001400R 90M-SP001400R PUSH SW TACT SW EVQ22505R CST1A023ZT
FRONT S204 90M-SP001400R 90M-SP001400R PUSH SW TACT SW EVQ22505R CST1A023ZT
FRONT S205 90M-SP001400R 90M-SP001400R PUSH SW TACT SW EVQ22505R CST1A023ZT
FRONT S206 90M-SP001400R 90M-SP001400R PUSH SW TACT SW EVQ22505R CST1A023ZT
FRONT S207 90M-SP001400R 90M-SP001400R PUSH SW TACT SW EVQ22505R CST1A023ZT
HEADPHONE PWB
(
CUP11983Z-2
)
H/P BK81 ns
p
ns
p
TERMINAL EARTH PLATE CMC1A278
H/P BN81
(
1
)
90M-FC500020R 90M-FC500020R FERRITE CORE D 30 M/M CLZ9W001Z
H/P BN81
(
2
)
ns
p
ns
p
CORD WIRE ASSY CWZCD6002BN81
H/P C801 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
H/P C802 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
H/P C803 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
H/P C804 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
H/P C805 ns
p
ns
p
CER. CAP. 1000PF 50V B HCBS1H102KBT
H/P C806 ns
p
ns
p
CER. CAP. 1000PF 50V B HCBS1H102KBT
H/P C807 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
POS. NO.
