Marantz CD6002/F - Page 45

53
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
H/P C808 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
H/P D801 90M-HZ200190R 90M-HZ200190R DIODE RLS4148SR HVDRLS4148SR
H/P D802 90M-HZ200190R 90M-HZ200190R DIODE RLS4148SR HVDRLS4148SR
H/P D803 90M-HZ200190R 90M-HZ200190R DIODE RLS4148SR HVDRLS4148SR
H/P D804 90M-HZ200190R 90M-HZ200190R DIODE RLS4148SR HVDRLS4148SR
H/P IC81 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
H/P PH81 F B ns
p
90M-YT003160R TERMINAL HTJ-064-05NG HEADPHONE JACK CJJ2E020Z
H/P PH81 F N ns
p
90M-YT003160R TERMINAL HTJ-064-05NG HEADPHONE JACK CJJ2E020Z
H/P PH81
/
K1G ns
p
90M-YT003160R TERMINAL HTJ-064-05NG HEADPHONE JACK CJJ2E020Z
H/P PH81
/
N1B 90M-YT003160R 90M-YT003160R TERMINAL HTJ-064-05NG HEADPHONE JACK CJJ2E020Z
H/P PH81
/
N1S 90M-YT004500R 90M-YT004500R TERMINAL JACK HEADPHONE
(
SILVER
)
CJJ2E026Z
H/P Q801 00MHT800951B0 00MHT800951B0 TRS. KTC3203Y HVTKTC3203YT
H/P Q802 00MHT800951B0 00MHT800951B0 TRS. KTC3203Y HVTKTC3203YT
H/P Q803 00MHT600141B0 00MHT600141B0 TRS. KTA1271Y HVTKTA1271YT
H/P Q804 00MHT600141B0 00MHT600141B0 TRS. KTA1271Y HVTKTA1271YT
H/P Q805 90M-HX800070R 90M-HX800070R CHIP TRS. KTC812TB HVTKTC812TB
H/P Q806 90M-HX800070R 90M-HX800070R CHIP TRS. KTC812TB HVTKTC812TB
H/P R801 ns
p
00MNN05472610 CHIP RES. 4.7K OHM 1/10W J CRJ10DJ472T
H/P R802 ns
p
00MNN05472610 CHIP RES. 4.7K OHM 1/10W J CRJ10DJ472T
H/P R803 ns
p
00MNN05472610 CHIP RES. 4.7K OHM 1/10W J CRJ10DJ472T
H/P R804 ns
p
00MNN05472610 CHIP RES. 4.7K OHM 1/10W J CRJ10DJ472T
H/P R805 ns
p
00MNN05152610 CHIP RES. 1.5K OHM 1/10W J CRJ10DJ152T
H/P R806 ns
p
00MNN05120610 CHIP RES. 12 OHM 1/10W J CRJ10DJ120T
H/P R807 90M-RI000330R 90M-RI000330R CHIP RES. 33 OHM 1/2W CRJ12EJ330T
H/P R808 ns
p
00MNN05120610 CHIP RES. 12 OHM 1/10W J CRJ10DJ120T
H/P R809 ns
p
00MNN05152610 CHIP RES. 1.5K OHM 1/10W J CRJ10DJ152T
H/P R810 90M-RI000330R 90M-RI000330R CHIP RES. 33 OHM 1/2W CRJ12EJ330T
H/P R811 ns
p
00MNN05152610 CHIP RES. 1.5K OHM 1/10W J CRJ10DJ152T
H/P R812 ns
p
00MNN05120610 CHIP RES. 12 OHM 1/10W J CRJ10DJ120T
H/P R813 90M-RI000330R 90M-RI000330R CHIP RES. 33 OHM 1/2W CRJ12EJ330T
H/P R814 ns
p
00MNN05120610 CHIP RES. 12 OHM 1/10W J CRJ10DJ120T
H/P R815 ns
p
00MNN05152610 CHIP RES. 1.5K OHM 1/10W J CRJ10DJ152T
H/P R816 90M-RI000330R 90M-RI000330R CHIP RES. 33 OHM 1/2W CRJ12EJ330T
H/P R817 ns
p
00MNN05750610 CHIP RES. 75 OHM 1/10W J CRJ10DJ750T
H/P R818 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
H/P R819 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
H/P R820 ns
p
00MNN05750610 CHIP RES. 75 OHM 1/10W J CRJ10DJ750T
H/P R821 ns
p
00MNN05472610 CHIP RES. 4.7K OHM 1/10W J CRJ10DJ472T
H/P R822 ns
p
00MNN05472610 CHIP RES. 4.7K OHM 1/10W J CRJ10DJ472T
H/P R823 ns
p
00MNN05750610 CHIP RES. 75 OHM 1/10W J CRJ10DJ750T
H/P R824 ns
p
00MNN05750610 CHIP RES. 75 OHM 1/10W J CRJ10DJ750T
H/P R825 ns
p
00MNN05472610 CHIP RES. 4.7K OHM 1/10W J CRJ10DJ472T
H/P R826 ns
p
00MNN05472610 CHIP RES. 4.7K OHM 1/10W J CRJ10DJ472T
H/P R827 ns
p
90M-NI001040R CHIP RES. 0 OHM 1/10W J CRJ10CJ0R0T
H/P R828 ns
p
90M-NI001040R CHIP RES. 0 OHM 1/10W J CRJ10CJ0R0T
H/P VR81 90M-RB000040R 90M-RB000040R VAR. RES. VOLUME
(
B CURVE
)
CVV2J02B103Z
MAIN PWB
(
CUP11983Z-1
)
MAIN BK31 ns
p
ns
p
HEATSINK HEAT SINK CMY1A267
MAIN BK71 ns
p
ns
p
BRACKET BRACKET FOR PWB CMD1A569
MAIN BK72 ns
p
ns
p
BRACKET BRACKET FOR PWB CMD1A569
MAIN BK73 ns
p
ns
p
BRACKET BRACKET FOR PWB CMD1A569
MAIN C301 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
MAIN C306 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
MAIN C313 ns
p
00MDD95470300 CER. CAP. 47PF 50V JA CCUS1H470JA
MAIN C314 ns
p
00MDK96333300 CER. CAP. 0.033UF 50V K CCUS1H333KC
MAIN C315 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
MAIN C316 ns
p
00MDK96153300 CER. CAP. 0.015UF 50V CCUS1H153KC
MAIN C317 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
MAIN C318 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
MAIN C319 ns
p
00MDK96472300 CER. CAP. 4700PF 50V KC CCUS1H472KC
MAIN C320 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
MAIN C321 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
MAIN C322 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
MAIN C323 ns
p
00MDK96153300 CER. CAP. 0.015UF 50V CCUS1H153KC
MAIN C324 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
MAIN C325 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
MAIN C326 ns
p
00MDD95680300 CER. CAP. 68PF 50V JA CCUS1H680JA
