Marantz DV4500 - Waveforms

E5PWF
WAVEFORMS
1-9-1
WF6
SPDIF
SPDIF
Pin 19 of CN1601
1V
1V
0.1
0.1
µ s
WF1 Pin 8 of CN1601
WF3 C1402 PLUS LEAD
WF4
AUDIO-L
AUDIO-L
Pin 14 of CN1601
1V
1V
0.5ms
0.5ms
WF5
AUDIO-R
AUDIO-R
Pin 16 of CN1601
1V
1V
0.5ms
0.5ms
WF2 Pin 10 of CN1601
VIDEO-Y
VIDEO-Y
0.2V
0.2V
20
20
µ s
VIDEO-C
VIDEO-C
0.2V
0.2V
20
20
µ s
VIDEO-CVBS
VIDEO-CVBS
0.5V
0.5V
20
20
µ s
NOTE:
Input
CD: 1kHz PLAY
(WF4~WF6)
DVD: POWER ON (STOP) MODE
(WF1~WF3)
